LDK 4426 3G Camera Triax to 3G Fiber Converter User’s Guide (v2.0)
19
Chapter 2 - Operation
Chapter 2
Operation
2.1 Indicator panel
During operation the indicator panel gives an overview of power and transmission
parameters:
STATUS
BS
PWR
LOC
PWR
CAM
TST
CAM
CON
Local Power
indicator
Camera Test
indicator
Base station
power indicator
Camera
connected
indicator
Triax signal
status indicator
Fiber signal
status indicator
Triax cable
quality bar
Fiber cable
quality bar
