Manual operation and setup
14.6 Using 3-D touch probes (Touch Probe Function software option)
14
432
TNC 620 | User's Manual for DIN/ISO Programming | 3/2014
Writing measured values from the touch probe cycles
in the preset table
Use this function if you want to save measured
values in the machine-based coordinate system (REF
coordinates). If you want to save measured values
in the workpiece coordinate system, use the
ENTER
IN DATUM TABLE soft key, See "Writing measured
values from the touch probe cycles in a datum table",
With the
ENTER IN PRESET TABLE soft key, the TNC can write
the values measured during a probe cycle in the preset table. The
measured values are then stored referenced to the machine-based
coordinate system (REF coordinates). The preset table has the
name PRESET.PR, and is saved in the directory TNC:\table\.
Select any probe function
Enter the desired coordinates of the datum in the appropriate
input boxes (depends on the touch probe cycle being run)
Enter the preset number in the
Number in table: input box
Press the
ENTER IN PRESET TABLE soft key. The TNC saves the
datum in the preset table under the entered number
