Technical Information 18.3
18
TNC 620 | User's Manual for DIN/ISO Programming | 3/2014
539
Touch probe function software option , (option number 17)
■ Compensation of tool misalignment in automatic mode
■ Datum setting in manual mode
■ Datum setting in automatic mode
■ Automatic workpiece measurement
Touch probe cycles
■ Automatic tool measurement
HEIDENHAIN DNC (option number 18)
■ Communication with external PC applications over COM component
Advanced programming features software option (option number 19)
FK free contour
programming ■ Programming in HEIDENHAIN conversational format with graphic
support for workpiece drawings not dimensioned for NC
■ Peck drilling, reaming, boring, counterboring, centering (Cycles 201 to
205, 208, 240, 241)
■ Milling of internal and external threads (Cycles 262 to 265, 267)
■ Finishing of rectangular and circular pockets and studs (Cycles 212 to
215, 251 to 257)
■ Clearing level and oblique surfaces (Cycles 230 to 233)
■ Straight slots and circular slots (Cycles 210, 211, 253, 254)
■ Linear and circular point patterns (Cycles 220, 221)
■ Contour train, contour pocket—also with contour-parallel machining
(Cycles 20 to 25)
Fixed cycles
■ OEM cycles (special cycles developed by the machine tool builder) can
be integrated
Advanced graphic features software option (option number 20)
■ Plan view
■ Projection in three planes
Program verification
graphics, program-run
graphics
■ 3-D view
Software option 3 (option number 21)
Tool compensation ■ M120: Radius-compensated contour look-ahead for up to 99 blocks
3-D machining ■ M118: Superimpose handwheel positioning during program run
Pallet management software option (option number 22)
■ Pallet management
Display step (Option number 23)
■ Linear axes down to 0.01 µm Input resolution and display
step
■ Rotary axes to 0.00001°
