1
0
.2 W
o
rk
ing with the P
a
ra
llel Ax
es U
, V and W
FUNCTION PARAXCOMP MOVE
The TNC uses the PARAXCOMP MOVE function to compensate for the
movement of a parallel axis by performing a compensation movement
in the associated principal axis.
For example, if a parallel axis moves in the negative W-axis direction,
the principal axis Z simultaneously moves in the positive direction by
the same value. The relative distance from the tool to the workpiece
remains the same. Application in gantry-type milling machine: Retract
the spindle sleeve to move the cross beam down simultaneously.
Proceed as follows for the definition:
U Show the soft-key row with special functions
U Select the menu for defining various plain-language
functions
U Select FUNCTION PARAX
U Select FUNCTION PARAXCOMP
U Select FUNCTION PARAXCOMP MOVE
U Define the parallel axis
Example: NC block
13 FUNCTION PARAXCOMP MOVE W
The PARAXCOMP MOVE function can be used only in
connection with straight-line blocks (L).
