Non-HEIDENHAIN devices
The connector layout of a non-HEIDENHAIN device may substantially
differ from that of a HEIDENHAIN device.
It depends on the unit and the type of data transfer. The table below
shows the connector pin layout on the adapter block.
Ethernet interface RJ45 socket
Maximum cable length:
„ Unshielded: 100 m
„ Shielded: 400 m
Adapter block 363 987-02 Connecting cable 366 964-xx
Female Male Female Color Female
1 1 1 Red 1
2 2 2 Yellow 3
3 3 3 White 2
4 4 4 Brown 6
5 5 5 Black 5
6 6 6 Violet 4
7 7 7 Gray 8
8 8 8 White/Green 7
9 9 9 Green 9
Hsg. Hsg. Hsg. Ext. shield Hsg.
Pin Signal Description
1 TX+ Transmit Data
2 TX– Transmit Data
3 REC+ Receive Data
4 Vacant
5 Vacant
6 REC– Receive Data
7 Vacant
8 Vacant
