HEIDENHAIN TNC 640

403

1

1

.6 Thr

ee-Dimensional T

ool Compensation (Sof

tw

ar

e Option 2)

Example: Block format with surface-normal vectors without tool
orientation

Example: Block format with surface-normal vectors and tool
orientation

LN X+31.737 Y+21.954 Z+33.165 NX+0.2637581 NY+0.0078922
NZ–0.8764339 F1000 M128

LN X+31.737 Y+21.954 Z+33.165 NX+0.2637581 NY+0.0078922
NZ–0.8764339 TX+0.0078922 TY–0.8764339 TZ+0.2590319 F1000
M128

LN

:

Straight line with 3-D compensation

X, Y, Z

:

Compensated coordinates of the straight-line end point

NX, NY, NZ

:

Components of the surface-normal vector

TX, TY, TZ

:

Components of the normalized vector for workpiece
orientation

F

:

Feed rate

M

:

Miscellaneous function
