16
Board Layout
Chapter 3
Embedded and Industrial Computing
External Connectors
The following picture highlights the location of external
input/output connectors. Refer to the table 3.3 Connector
List for more details.
DVID1
USB1
LAN1/LAN2
HDMI1
USB3
USB2
RST1
VGA1
CN4
LED1
LEB-5570
CN3/
DCJK1
(optional)
