Board Layout
Chapter 3
Embedded and Industrial Computing
Connectors and Jumpers List
The tables below list the function of each of the board
jumpers and connectors by labels shown in the above
section. The next section in this chapter gives pin
definitions and instructions on setting jumpers.
Table 3.1 Connector List for LEK-IOA7 Board
Labels Function Pin Definition Reference
Page
AUDIO1 HD Audio Connector (D-Sub) P20
CN3 48V for PoE Power Supply P21
CN4 DC_in and out Connector P21
COM1 RS232/422/485 Serial Port P20
COM2 RS232/422/485 Serial Port P20
J13/J14 Select COM1 and COM2 Pin9 Function P21
JAUD1 Audio Select P22
LAN1~LAN8 POE Ports P22
MIO1(J15) Digital Input and Output P21
MIO Connector to the LEB-5570 board P22
SCT1/SCT3 Select COM2 Protocol Setting P20
SCT2/SCT4 Select COM1 Protocol Setting P20
SSDSLT1 SSD enable/disable P22
Table 3.2Connector List for LEK-IG1 Board
Labels Function Pin Definition Reference
Page
CN1 MCU Programming Connector P27
IGNITION1 Ignition Control Connector P27
IGN_CON1 Power Connector P27
SW1 Power Ignition Behavior Switch P27
The ignition board also equips with jumpers that can be switched to enable or disable automatic power management control.
Table 3.3 Connector List for LEB-5570 Board
Labels Function Pin Definition Reference
Page
CMOS1 Cleaning CMOS Data Including RTC P26
CMOS2 Cleaning CMOS Data Only P29
COMSLT1 Daughter board LEK-IOA7 enable/disable P25
COMSLT2 Daughter board LEK-IG1 enable/disable P26
CN43 Power Connector with Power -ignition Control P25
DCJK1 (optional) Optional DC Jack Type of Power Connector P25
DVID1 DVI-D Connector P24
FAN1/FAN2 System Fan Connector P24
Front1 Front Panel Function Pin Header P23
HDMI1 HDMI Port P24
Ignition1 Connector for power Ignition Control P26
J1 PEG16X Lane Function Selection P24
KBM1 PS/2 Keybaord and Mouse Connector P26
LAN1/LAN2 Ethernet Connector 1/Ethernet Connector 2 P25
LPC1 Low Pin Count Interface Reserved for factory use
MIO1 COM and Audio Expansion Card Connector (to the LEK-IOA7) P23
MPCIE1 Mini-PCIe Connector P25
MPCIE2 Mini-PCIe Connector P25
RST1 Reset Button P24
SATA1/SATA2 Serial-ATA Connector (SATA2 supports SATA-DOM) P23
SATA_PWR1 SATA Power Connector P23
SATA_PW2 Switch for SATA port 2 power state P23
SIM1 SIM Card Reader P25
SPI1 Serial Peripheral Interface Bus Reserved for factory use
USB1/USB2/USB3 USB Type A Connector #0,1; #2,3; #4,5 P26
VGA1 VGA Port P24
