21


JP2：4 Pin TACT Power Button








2

1

○

_

○

○

4

3








PIN NO.

DESCRIPTION

1

Ground

2

Ground

3

PS_ON#

4

PS_ON#


JP3：4 Pin TACT Reset Button








2

1

○

_

○

○

4

3








PIN NO.

DESCRIPTION

1

Ground

2

Ground

3

PS_ON#

4

PS_ON#
