same Policy Number.
2. Policy Entry #: Displays Policy entry number (read-only).
3. Policy Number: Displays the Policy number of the configuration. This number corresponds to the Alert
Policy Number field in the modify/add Event Filter entry (see section 5.6.1 above).
4. Policy Configuration: Select to enable the policy settings.
5. Policy Set: Select any one of the Policy set values from the list. It defines how the alert should be sent to the
(multiple) destinations depending on the following described rules. The priority of multiple LAN destinations
is determined by the Policy Entry #.
0 - Always send alert to this destination.
1 - If alert to previous destination was successful, do not send alert to this destination. Proceed to next entry
in this policy set.
2 - If alert to previous destination was successful, do not send alert to this destination. Do not process any
more entries in this policy set.
3 - If alert to previous destination was successful, do not send alert to this destination. Proceed to next entry
in this policy set that is to a different channel.
4 - If alert to previous destination was successful, do not send alert to this destination. Proceed to next entry
in this policy set that is to a different destination type.
6. Channel Number: Choose a particular channel from the available channel list.
7. Destination Selector: Choose a particular destination from the configured destination list.
NOTE : The LAN Destination has to be configured via the LAN Destination tab under
Configuration->PEF->LAN Destination .
8. Enable the check box if the Alert policy entry is Event Specific.
9. Choose any value that is used to look up the Alert String to send for this Alert Policy entry. If the Event
specific is selected (above), then the value is used in conjunction with Event filter Number to lookup the Alert
String from the PEF configuration Parameters. If the Event Specific is not selected, it directly selects an alert
string from the PEF Configuration Parameters.
The Alert String is used for a Dial Page. The combination of Event Filter Entry and alert destination are used
to select a given Alert String from a set of strings kept in the PEF (Platform Event Filtering) configuration
parameters. This enables different strings to be sent based on what event filter was matched and where
the alert is being sent.
NOTE : The PEF Configuration Parameters are set by the PEF commands which configure and control the
Platform Event Filtering (PEF) and Alerting capabilities. For more information, contact Lanner
10. Click Add to add the new event filter entry or Cancel to cancel this entry and return to Event filter list
