Casio LK-170 - Manual (Page 18)

Sampling a Sound and Playing it on the Keyboard (Sampling)
EN-16
Use the following procedure to replace a percussive
instrument with a sampled sound you sampled with short
sampling and play auto accompaniment rhythms (page
EN-28) with it.
1.
Each press of cl (VOICE PERCUSSION) button
toggles between the VOICE PERCUSSION mode
and the normal rhythm mode.
• The VOICE PERCUSSION indicator will be on the
display while the VOICE PERCUSSION mode is
selected.
2.
Start rhythm play (page EN-28).
• Some rhythm part sounds are replaced by sampled
sounds you sampled with short sampling.
• In the VOICE PERCUSSION mode, the rhythm
accompaniment volume level is balanced with the volume
of the sampled sound. Because of this, the rhythm
accompaniment (chords and obbligato) volume level will be
lowered automatically.
1.
Press 3 (FUNCTION) a number of times until
“SampAuto” appears on the display (page
EN-4).
2.
Press bp (10-key) [–] key to select the OFF
setting.
This enables manual sampling. When this setting is
selected, sampling starts as soon as you release
cq in
step 2 under “Long Sampling” (page EN-12) or step 2
under “Short Sampling” (page EN-13).
• When the above setting is “oFF”, sampling starts when
you release cq , not when you press it. Sampling will
not start if you keep cq depressed.
1.
Press 1 to turn off power.
2.
While holding down bo (SONG BANK) and bp
(10-key) [0] button, press 1 to turn power back
on again.
• Make sure the digital keyboard is not connected to a
computer when performing the above steps. Otherwise,
data may not be deleted correctly.
1.
Press bo (SONG BANK).
2.
Hold down bq (SAMPLED TONES/EFFECTS 1).
• This will cause the confirmation message “Sure?” to
appear.
3.
Press bp (10-key) [YES] key to delete the data
or bp (10-key) [NO] key to cancel.
1.
Press bn (RHYTHM).
2.
Hold down the SAMPLED TONES/EFFECTS
button (
bq to ck ) whose data you want to
delete.
• This will cause the confirmation message “Sure?” to
appear.
3.
Press bp (10-key) [YES] key to delete the data
or bp (10-key) [NO] key to cancel.
Using a Sampled Sound in a
Rhythm (VOICE PERCUSSION)
Starting a Sampling Operation
Manually
Lights
S a m p A u t o
Deleting Sampled Data
To delete all sampled data
To delete the long sample
To delete the data for a specific short sample
number
LK260_A5_x1a_EN_ES.indd 18 2014/02/21 15:07:00
