General Guide
EN-3
• The following explains the meaning of the $ symbol that appears on the product console and with the key names below.
$ : Indicates a function that is enabled by holding down the button for some time.
1 P(POWER) button ☞EN-6
2 VOLUME slider ☞EN-6
3 FUNCTION button ☞EN-4
4 METRONOME, $ BEAT button ☞EN-8
5 TEMPO buttons ☞EN-8, 20, 32
6 REPEAT, INTRO button ☞EN-19, 31
7 REW, NORMAL/FILL-IN button ☞EN-19, 31
8 FF, VAR./FILL-IN button ☞EN-19, 31
9 PAUSE, SYNCHRO/ENDING button ☞EN-19, 31
bk PLAY/STOP, START/STOP button ☞EN-12, 19, 28
bl PART SELECT, ACCOMP/ $ CHORDS button
☞ EN-21, 29
bm TONE, SAMPLING DEMO button ☞EN-9, 12
bn RHYTHM, ONE TOUCH PRESET $ button
☞ EN-13, 28, 32
bo SONG BANK button ☞EN-12, 18
bp Number buttons, [–]/[+] keys ☞EN-4
bq SAMPLED TONES/EFFECTS 1, LISTEN button
☞
EN-15, 24
br SAMPLED TONES/EFFECTS 2, WATCH button
☞
EN-15, 24
bs SAMPLED TONES/EFFECTS 3,
REMEMBER button ☞EN-15, 25
bt SAMPLED TONES/EFFECTS 4, NEXT button
☞
EN-15, 23
ck SAMPLED TONES/EFFECTS 5, AUTO button
☞
EN-15, 26
cl VOICE PERCUSSION, LESSON button ☞EN-16, 23
cm Speakers
cn Song Bank list
co Built-in microphone
cp Display
cq SAMPLING button ☞EN-12
cr Rhythm list
cs Tone list
ct CHORD root names ☞EN-29
dk Percussion instrument list ☞EN-9
dl dm dp dn do dq dr
dl USB port ☞EN-33
dm SUSTAIN jack ☞EN-10
dn MIC VOLUME knob ☞EN-12
do MIC IN/SAMPLING jack ☞EN-12
dp AUDIO IN jack (LK-260 only) ☞EN-36
dq DC 9.5V terminal ☞EN-5
dr PHONES/OUTPUT jack ☞EN-6, 36
■ Back
