2
Brinbourne ™ 3 Light Fixture
Fig. 2
Fig. 1
3. REMOVING THE DECORATIVE CAP
4. INSTALLING THE LIGHT FIXTURE
NOTE: This ceiling fan light fixture is
specifically designed to fit the Kichler
®
Brinbourne™ Ceiling Fan 300262. It will not fit
or work with ANY OTHER ceiling fan.
1. Attached the new mounting plate by placing
the keyholes over the two screw heads
previously loosened, rotate the mounting plate
so the screw heads are at the narrow end of
the keyholes. Replace the third screw and
tighten all three screws. (see figure 2).
Screws
Bottom housing
Mounting plate
cover
Screws
Bottom housing
Plug
Mounting plate
Decorative cap
Step 1. Remove the Plug and Decorative Cap
from the ceiling fan by unscrewing the Plug.
(see figure 1)
Step 2. Remove the Mounting Plate by
removing two of the three screws around the
outside edge of the plate and loosing the third.
Rotate the mounting plate so the remaining
screw heads are in the large end of the
keyhole slots and remove the plate. (see
figure 1)
