Florabest FHL 900 A1 - Manual (Page 45)

45
MT GB
jammed material. A moment of
inattention while operating the hedge
trimmer may result in serious personal
injury.
• Carry the hedge trimmer by the handle
with the cutter blade stopped. When
transporting or storing the hedge
trimmer always fit the cutting device
cover. Proper handling of the hedge
trimmer will reduce possible personal
injury from the cutter blades.
• Keep cable away from cutting area.
During operation the cable may
be hidden in shrubs and can be
accidentally cut by the blade.
Intended Use
The equipment is specified for use only
for the cutting and trimming of hedges,
bushes and ornamental shrubs in the
domestic environment. Any other use that
is not explicitly approved in these instruc-
tions may result in damage to the equip-
ment and represent a serious danger to
the user.
The equipment is designed for use by
adults. Adolescents over the age of 16
may use the device only under supervi-
sion. Do not use the hedge trimmer in the
rain or on wet hedges.
The operator or user is responsible for ac-
cidents or damage to other people or their
property.
The manufacturer is not liable for dam-
ages caused by unspecified use or incor-
rect operation.
Before use, check that the blades
are sharp. Ensure that the blades
are sharpened whenever blunt, in
order to avoid overstressing of the
machine. Damages caused by cut-
ting with blunt blades are not cov-
ered by the guarantee.
General Description
See the front fold-out page for
illustrations.
Function Description
The electric hedge trimmer is driven by
an electronic motor. The equipment is
double-insulated for safety and does not
require earthing.
The hedge trimmer is equipped with a
double-sided safety cutter bar. When
cutting, the blades move backwards and
forwards in linear motion. The impact pro-
tection on the tip of the cutter bar prevents
unpleasant recoils should the trimmer
come into contact with walls, fences and
so on.
The unit can only be operated with the
deadman switch depressed, in order to
protect the operator. In addition, the hand
guard protects against branches and
briars.
Please note the following descriptions for
the function of the operating components.
Overview
A 1 Safety blade
2 Gearbox
3 Lubrication port
4 Stop lever fixing
5a Stop lever
5b Safety lever
6 Handle for adjusting the blade
beam
7 Front arm
8 Safety button
9 Pivotal centre
10 Round handle
11 Safety slide
12 Deadman switch
13 On/off switch
14 Mains cable
15 Shoulder strap
16 Eye (for shoulder strap)
17 Leg protection
18 Blade protection
