Florabest FHL 900 A1 - Manual (Page 49)

49
MT GB
Maintenance/Cleaning
Repair and servicing work not
described in this manual should
always be carried by our Service
Centre (see p.69 for address). Use
only original parts.
Pull out the power plug before car-
rying out any work on the equip-
ment.
Wear gloves while handling the
blades.
Carry out the following maintenance and
cleaning work regularly. This will guarantee
a long and reliable service life.
• Before each use, check the hedge
trimmer for obvious defects such as
loose, worn or damaged parts. Check
the secure seating of the bolts in the
cutter bar.
• Do not use the unit if the blades are
blunt or worn. This will overstress the
motor and gearbox of the machine.
• Check coverings and safety devices for
damage and correct seating. Replace
these where necessary.
• Keep the ventilation slots and motor
housing of the device clean. Use a
damp cloth or a brush to do this. Do
not wash down the equipment with wa-
ter, or submerge it in water.
• Do not use any cleaning agents or sol-
vents. These could cause irreparable
damage to the equipment. Chemical
substances can attack the plastic parts
of the equipment.
• Clean the cutter bar carefully after
each use. Wipe it off with an oily cloth
or spray it with a metal protective
spray.
• Keep the hedge trimmer dry and cov-
ered with the blade protection supplied
and out of reach of children.
Lubricating the Gears
F
The angular gearbox requires
lubrication after approx. 20 operating
hours.
To do this, use the lubrication port (3)
to press up to 5g standard grease into
the gearbox (2).
To do this, remove the locking screw
on the lubrication port (3) and grease
the gears. Then reclose the lubrication
port using the locking screw.
Storage
• Keep the trimmer in the blade guard
supplied, in a dry place and out of
reach of children.
Spare Parts
Replacement parts may be ordered di-
rectly from our Service Centre (see p.69
for address).
When ordering, always specify the ma-
chine type and the part number in the
exploded drawing.
Power cable .................. Art.-Nr. 91096542
Guarantee
This unit has a guarantee period of 36
months, or 12 months for units used on a
commercial basis or for replacement units
according to the statutory regulations. The
guarantee does not include damages that
are attributable to natural wear, overloading
or inappropriate use. Certain component
parts are subject to normal wear and are
excluded from the guarantee. In particular,
cutter bars, eccentric drives and carbon
brushes are included here, providing the
complaints cannot be attributed to material
defects.
