47
MT GB
(5a) to release the safety blade
beam fixing (
A
1).
4. The safety blade beam (
A
1)
can now be swivelled out into
the operating position. Use the
stop stages and allow the stop
lever (5a) and safety lever (5b)
to click back in.
5. Screw the stop lever fixing (4)
back into the stop lever (5a).
Attach the shoulder strap
Attach the shoulder strap spring clip
( A 15) to the carrying eyelet ( A 16) on
the tubular shank of the device.
Switching On and Off
Ensure that you are standing in a
firm position with both hands grip-
ping the hedge trimmer away from
the body. Ensure that the trimmer
is in contact with no other objects
before switching on.
1. Connect the device to the mains
voltage.
2. To switch on, hold the safety
switch (
A
13) depressed and
simultaneously press the on/
off switch (
A
14). The hedge
trimmer will be run at maximum
speed.
3. The equipment will switch off
again when you release on/off
switch (
A
14).
Working with the Electric
Hedge Trimmer
During cutting work, ensure that no
contact is made with objects, e.g.
such as wire fencing or main plant
stems. This may result in damage
to the cutter bar.
• Always hold the equipment firmly in
both hands, with one hand on the rear
handle and the other on the front han-
dle. Thumbs and fingers must be firmly
around the handles.
• Switch off the equipment immedi-
ately in the event that the blades are
blocked by solid objects, pull out the
power plug then remove the object.
• Always work away from the mains pow-
er outlet. Set the cutting direction before
starting work. Ensure that the power
cable is kept well away from the work-
ing area. Never lay the cable over the
hedge, where it could easily be caught
up in the trimmer blades.
• Avoid overstraining the equipment dur-
ing work.
Pull out the power plug imme-
diately if the cable is damaged,
badly twisted or has been com-
pletely cut through.
Swivelling the Arm
Caution!
The gear box (
A
2) becomes
hot during operation. There is
a risk of burns. Do not touch
the gearbox housing ( A 2) or
the connection to the front arm
( A 7).
E
1. Release the indexing by
pushing the safety slide (11)
forward.
2. The tubular shank can now
optionally be turned 45° / 90°
to the right or the left (see the
scale on the device).
Cutting Techniques
• Cut thick branches beforehand using a
branch clippers.
• The double-sided cutter bar enables
cutting in both directions or, with a
