32 GB
Start-up Safety / Preparation / Installation
at all times. Never install the light if you are hav-
ing difficulty concentrating or do not feel well.
Preparation
Required tools and material
The tools and materials specified are not included.
This information and these values are non-binding
and are only provided as a reference. The nature
of the material is determined by the individual local
conditions.
- Pencil / making tool
- Voltage tester
- Screwdriver
- Electric drill
- Bit (approx. 0.6 cm)
- Side cutting pliers
- Ladder
Prior to installation
Important: The electrical connection must be
established by a trained electrician or a person
trained to perform electrical connections. This per-
son must be familiar with the properties of the light
and the connection regulations.
Familiarise yourself with all the instructions and
diagrams in this manual, as well as with the
light itself, before you install it.
Before installation ensure that the circuit, to
which the light will be connected, is not ener-
gised. To do so, remove the fuse or switch off
the circuit breaker in the fuse box (0 position).
Use the voltage tester to verify the de-ener-
gised status.
Installation
Mounting the light
Prior to installation, remove the fuse or switch
off the circuit breaker (0 setting) in the fuse box.
Remove the screws 4 visible at the side of the
connection housing 2 and remove the mount-
ing bracket 1 at the back.
Use the slotted holes intended for the mounting
bracket 1 to mark the bores.
Now drill the fixing holes (approx. 6 mm, depth
approx. 35 mm). Ensure that you do not dam-
age the supply line.
Insert the rawlplugs 3 into the holes. Fasten
the mounting bracket 1 with the provided
screws 5 .
Open the plastic housing 12 . Then feed the
mains connection cable (external) 14 through
the protective tube 13 on the plastic housing 12 .
Now connect the connection cable of the light
to the mains connection cable (external)
14 us-
ing the terminal block 15 . Be sure to correctly
connect the individual wires of the mains con-
nection cable (external)
14 : live wire, black or
brown = symbol L, neutral wire, blue = symbol N).
Close the plastic housing 12 .
Use the screws 4 to fasten the luminaire to
the mounting bracket 1 .
Remove the nuts 8 and plastic rings 7 from
the lamp bulb sockets 11 .
Attach a lamp shade 6 onto each bulb
socket 11 .
Secure the lamp shades 6 with the plastic
rings 7 and the nuts 8 using the tool.
Use a clean, lint-free cloth when inserting the
light bulb 10 .
Carefully insert the light bulb 10 into the socket.
Check for correct fitting.
Reinsert the fuse or switch the circuit breaker
back on.
Your light is now ready to use.
