Problem Solver
131
5
5
5
5
5
5
5
5
5
5
5
5
Follow these steps to perform the bidirectional adjustment:
1. Make sure paper is loaded, then turn off the printer.
c
Caution:
Whenever you turn off the printer, wait at least five seconds
before turning it back on; otherwise you may damage the
printer.
2. While holding down the Pause button, turn on the printer.
The printer enters the bidirectional adjustment mode and
then prints instructions and the first set of alignment patterns.
3. As described in the instructions, compare the alignment
patterns and select the aligned pattern number with the best
alignment by pressing the Font (ItemU) or Pitch (ItemD)
button. The LCD shows the pattern number that is selected at
the time. Press the SetD (Top of Form) button to fix the
selected pattern number, and the next set of alignment
patterns is printed.
4. Select the pattern with the best alignment for each of the
remaining sets of alignment patterns.
5. After you select the best pattern in the final set of alignment
patterns and save your selection by pressing the SetD (Top of
Form) button, turn off the printer and exit the bidirectional
adjustment mode.
