WatchIN Installation Manual 13
Barrier lens (RL327B): Top view
Feet
0 10 20 30 40 50
2 4 6 8 10 0 12 14 16
2
18 20 22 24
0
2
60 70 80
0
10
10
Meters
Feet Meters
90
26 27
5°
Barrier lens (RL327B): Side view
0
10
1
3
0
2 4 6 8 10 0 12 14 16 18 20 22
0 10 20 30 40 50 60
24 26 27
70 80 90
Meters
Feet
Meters
Typical
Installation
Height:
2.4m (7'10")
Note:
All detection patterns are assured and approved according to EN50131 in Normal sensitivity settings
(factory default).
If you change the sensitivity setting, the actual detection pattern must be assured during installation.
