WatchIN Installation Manual

Notes:

Virtual BUS zones are cost effective. They enable to expand your system zones without adding physical
zone expanders.
The virtual BUS zone expander can be used only for BUS zone detectors.
To add a BUS zone expander select type BZ08 or BZ16 when adding a zone expander (Quick key [7][1][2]).

1. To Add / Delete the WatchIN DT

1. From the installer menu enter the Add/Delete menu: Quick Key [7][1][9][5] for BUS

Zones detectors.

2. Use the

keys to position the cursor over the BUS

Zone ID number for which you want to assign (or delete) a detector.

Note:

Make sure that the detector's physical ID number is identical to the ID number you select during programming.

3. Place the cursor on the TYPE field and use the

key to select IDT25 for

the WatchIN DT detector.

4. Press

to confirm.

5. Repeat the process for the other BUS detectors.

2. Assigning the WatchIN DT to a Zone

1. From the main installer menu enter Zones: One by One option (Quick key [2][1])

2. Select the zone number that you want to assign the BUS detector.

Note:

If you have defined a BUS Zone Expander, select a zone number from the virtual zones (defined by the BUS
zone expander).

3. Define Partitions, Groups, Zone Type and Zone Sound.

4. In the Termination category select [5] BUS Zone followed by

The following display appears:

Z:001 LINK TO:

ID:01 TYPE=IDT25

5. Select the BUS zone number to assign to the programmed zone. The type field will be

updated automatically when selecting the zone.

6. Press

. The loop response category is not applicable to a BUS zone

and the following display appears:

Z:001 RESPONSE:

N/A-BUS ZONE

Z:001 RESPONSE:

N/A-BUS ZONE

7. Press

, assign label and press

Configuring the WatchIN DT Parameters

1. To access the WatchIN settings option press [2][0][3] from the main installer menu.

The following display appears:

B- ZONE PRMS:

ZONE#=001 (0:01)

2. Select the zone that the BUS zone was assigned to and press

. You

can now program the WatchIN parameters as follows:
