4 Channel DVR 120(100) 120(100) 120(100) 120 60
8 Channel DVR 240(200) 240(200) 240(200) 240 120
16 Channel DVR 480(400) 480(400) 480(400) 480 240
H Type
360x 240(288) 720x240(288) 720x480(576) 1280 x 720 1920 x 1080
4 Channel DVR 120(100) 120(100) 120(100) 120 100
8 Channel DVR 240(200) 240(200) 240(200) 240 200
16 Channel DVR 480(400) 480(400) 480(400) 480 400
I Type
 HD-SDI Input (CH 1~2)

360x 240(288) 720x240(288) 720x480(576) 1280 x 720 1920 x 1080
2 Channel 60(50) 60(50) 60(50) 60 50

Analog Input (CH 3~16)
NTSC(PAL) 360x240 (360x288) 720x240 (720x288) 720x480 (720x576)
14 Channel 420 (350) 420 (350) 210 (175)
 Click ( ) each frame on ‘Quality’ column to select recording quality of a corresponding camera. User may select its
recording quality from Super, High and Std.
 Click ( ) each frame on ‘Duration’ column to select recording duration (i.e., 1 second ~3 hours) of a corresponding camera.
 User may change the setting values of Resolution, Frames, Quality and Duration at a time by clicking the menu tab.
 Choose ‘OK’ to confirm the setting.
NOTE
For H and I Type, users can select the input standard from 720P 24, 720P 25, 720P 30, 720P 50, 720P 60, 1080I 50, 1080I 60, 1080P 24,
1080P 25, 1080P 30, 1080P 50, 1080P 60 (Manual Selection)
NOTE
For F and G Type, DVR will automatically detect the input signals from 720P 24, 720P 25, 720P 30, 720P 50, 720P 60, 1080I 50, 1080I 60,
1080P 24, 1080P 25, 1080P 30, 1080P 50, 1080P 60 (Auto Detection).
CAUTION
If the HD-SDI input signal is 1080p, then the frame resolution of 360 x 240, 720 x 240 and 720 x 480 are decreased in half.
 Please click ( ) Event and the following screen will appear.
 The Event menu will allow user to set Event videos.
 Each frame on Title column shows camera title registered in DEVICES>Camera/PTZ. User cannot change camera titles
here.
 Click ( ) each frame on Resolution column to select recording resolution of a corresponding camera. User may select one
Event
