6-18
Using Various Functions > Functions
Staple/Punch
Staple
Staples the finished documents. The staple position can be selected.
Original Orientation and Staple Position
Item Value Description
Staple Top Left Select the staple position. For details on original orientation
and staple position, refer to
Original Orientation and Staple
Position on page 6-18 .
Top Right
2 staples Left
2 staples Top
2 staples Right
Original
Orientation Top Edge on Top, Top Edge on Left Select the orientation of the original document top edge to
scan correct direction. Press [Original Orientation] to choose
orientation of the originals, either [Top Edge on Top] or [Top
Edge on Left]. Then press [OK].
NOTE
Stapling requires the optional 1,000-Sheet Finisher.
For details on paper sizes and numbers of sheets that can be stapled, refer to
1,000-Sheet Finisher (Option) on page
11-26 .
Original orientation Top Edge on Top Top Edge on Left
Paper orientation
Cassette paper load
direction
Cassette paper load
direction
NOTE
B5-R and 16K-R "one staple" is not diagonal.
