Installing and Setting up the Machine > Part Names

Connectors/Interior

1 Network Interface Connector

2 USB Port (A2)

3 USB Interface Connector (B1)

4 Option Interface

5 Toner Container (Yellow)

6 Toner Container (Cyan)

7 Toner Container (Magenta)

8 Toner Container (Black)

9 Waste Toner Box
