30
6. Export: to save/export the data (i.e. the Voltage/Current curve data) of
Present Sample as/in a .CSV file for users to read in Excel.
7. I/V CURVE: to select the X-axis of the present curves based on I or V.
8. Print: to print out the present LCD data.
9. Redraw: users can move the cursor in the diagram to change the cursor
position.When users move the cursor and make the whole diagram
disordered, they can press “Redraw” button to make the present
diagram returned to the initial status.
Note:
1. After exporting logged data, they can’t be read (imported) anymore.
Please read them in the Excel software.
2. If it is necessary to read the logged data in the future, please be sure to
perform the Save/Open (logged data) functions.
