8 9
Installing the 2-in-1 Charging & Storage Mount
1. The 2-in-1 charging & storage mount should be installed in a
cool, dry place with an electrical outlet nearby. Prior to installing,
ensure that there are not any wires or pipes in the space directly
behind where the mount will be installed.
2. The bottom of the mounting template sticker should be level
and at least 1.03 m from the ground, and its top should have at
least 30 cm of clearance above it. 3. Use a power drill with an 8 mm drill bit to drill a hole into each
hole marker on the mounting template sticker, then insert a wall
plug into each hole.
4. Align the mounting holes on the 2-in-1 charging & storage mount
to the holes on the wall, then attach the mount to the wall using
the included screws.
Recommended Height: At least 1.03 meters from the ground
How to Install
Display Screen
The number on the display screen represents the current battery
level in a percentage during charging. When the number turns into
100, the battery is fully charged.
Charging the vacuum cleaner on the charging mount
Charging
Notes:
Fully charge the vacuum cleaner before using it for the first time.
This will take about 4 hours.
The vacuum cleaner cannot be used while charging.
Vacuuming at the highest suction level for a prolonged period will
cause the battery to heat up, which may increase the charging
time. Before charging the vacuum cleaner, it is better to cool it
down for 30 minutes.
103 cm
30 cm
* The replaceable battery is not included and purchased separately.
Extended Dock Charging Plate
Extended Dock
You can simultaneously charge the replaceable
battery* when charging the vacuum cleaner on the
2-in-1 charging & storage mount.
Mounting Template
Sticker
Screw Wall Plug
Battery Status Indicator
Charging the vacuum cleaner with the charger
Off Blinking On
Once the vacuum cleaner is fully charged, the indicator will turn off after 5
minutes, and the vacuum cleaner will then enter the energy-saving mode.
Low battery
Fully charged
Half battery
Nearly full
Battery Status
Indicator
2
1
Charging
Port
Charging
Contacts Ч 2
