The Black Low Pass VCF has a hidden feature – the Black Filter Coupler connector. The Erica Synths
Black Filter Coupler is a satellite module for the Black High Pass and the Black Low Pass VCFs, and it
adds versatile Bandpass and Band Reject filter functionality to your modular system.
Please note, that the Black Filter Coupler works only with Erica Synths modules and you need both
Black High Pass and Low Pass VCFs.
Transport the instrument carefully, never let it drop or fall
over. Warranty does not apply to modules with visual
damages.
The module has to be shipped in the original packaging
only. Any module shipped to us for return, exchange and/or
warranty repair has to be in its original packaging. All other
deliveries will be rejected and returned to you. Make sure
you keep the original packaging and technical documentation.
This device complies to the EU guidelines and is manufac-
tured RoHS conforming without use of lead, mercury,
cadmium and chrome. Nevertheless, this device is special
waste and disposal in household waste is not recommended.
User manual by Girts Ozolins@Erica Synths.
Design by Ineta Briede@Black8.
Copying, distribution or any commercial use in any way is
prohibited and needs the written permission by Erica Synths.
Specifications are subject to change without notice.In case of
any questions, feel free to contact us through www.erica-
synths.lv.
You will find Erica Synths terms of warranty at
www.ericasynths.lv
Items for return, exchange and/or warranty repair have to
be registered at SUPPORT on www.ericasynths.lv and send
back to us according to instructions in the support page.
SAFETY INSTRUCTIONS
Please follow the instructions for use of the Erica Synths module below,
‘cause only this will guarantee proper operation of the module and
ensure warranty from Erica Synths.
Water is lethal for most of the electric devices, unless they are made
waterproof. This Erica Synths module is NOT intended for use in a
humid or wet environment. No liquids or other conducting
substances must get into the module. Should this happen, the
module should be disconnected from mains power immediately,
dried, examined and cleaned by a qualified technician.
Do not expose the module to temperatures above +50° C or below
-20° C. If you have transported module in extreme low temperatures,
leave it in room temperature for an hour before plugging it in.
CUTOFF
IN LEVEL
CV1 LEVEL
RESONANCE
RESO CV LEVEL
INPUT CV1 CV2 OUT
BLACK HIGH PASS VCF
RESO CV IN
ON
OFF
DRIVE
CUTOFF
IN LEVEL
CV1 LEVEL
RESONANCE
RESO CV LEVEL
INPUT CV1 CV2 OUT
BLACK LOW PASS VCF
0
RESO CV IN DRIVE
ON
OFF
BW CV CF CV
OUT IN2 IN1
BLACK VCF COUPLER
BR
OFF
BP
MODE
CENTER FREQ
CF CV LVL
BANDWIDTH
Remove the jumper and
connect the Erica Synths Black
Filter Coupler. 2x5pin ribbon
cable is supplied with the
Black Filter Coupler module.
Use this trimpot to adjust
post-filter overdrive to your
taste.
