PICO
VCF1
Use this knob to adjust VCF cutoff
manually
Choose between LP and BP modes
Use this knob to adjust VCF Resonance
manually
This knob adjusts cutoff CV level
Patch audio signal here
This is VCF output
Patch cutoff CV signal here
PICO
OUT
RESO
C-OFF
LP
BP
CV IN
IN
CV IN
VCF1
