Chapter 1 Getting started 1-15
Features and specs
Dimensions
Height
421.38mm(16.59in.)
Depth
219.97 mm (8.66 in.)
Width
613.80 mm (24.16 in.)
Stand
Tilt range
Range: -5°/+
35
°
Swivel
Range: -45°/+45°
Lift
Range: 135mm
Pivot
90 degree (both clockwise and
counter clockwise)
VESA mount
Supported (GS&UL Approved) 100 mm x 100 mm
(3.94 in. x 3.94 in.)
Viewable image size
684.784 mm (27 in.)
Maximum height
335.664mm(13.21in.)
Maximum width
596.736mm (23.49in.)
Pixel pitch
0.1554mm (0.0061 in.) (V)
Response time
Normal: 6 ms
Extreme: 4 ms
Power input
Supply voltage
100-240 VAC, 60/50 Hz
current
3.5A
Thunderbolt upstream port
PD Function
Supply voltage/Watt
5V/9V/15V/20V
<65 W (Typical)
<96 W (Max) in Smart Power
Mode
Thunderbolt downstream port
PD Function
Supply voltage/Watt
5V/9V/15V
27W Max.
USB Type C PD Function
Supply voltage/Watt
5V/9V/12V
27W Max.
Power consumption
Note:
Power consumption
figures are for the monitor
and the power delivery
together.
Max Consumption
240W
Typical Consumption
35W
Standby/Suspend
<
0.5W
Off
<
0.3W
Video input (DP)
Input signal
DP
Horizontal addressability
3840 pixels (max)
Vertical addressability
2160 lines (max)
Clock frequency
600 MHz
Table 1-1. Monitor specifications
