Page | 22 ICE-HE-DXL Display Control Center Product Manual 042021
Groups
Individual TVs must be assigned to a group. A minimum of one group is required. Each Group button may be renamed. The Label field
supports up to ten characters. To create a new group, just assign a TV to a group number that is not used. To delete a group, reassign all
TVs in that group to another group.
Channels
Channels may be added or deleted. Each Channel button may be renamed. The Label field supports up to ten characters. To add a channel,
select an existing channel, modify it with the new channel settings and click
Add . The new channel will be added in the same column as the
initial channel that was selected for modification.
Display Express Lite will automatically format the iCC-Net channel command string with the correct tuning style based on the settings
entered in the Edit Channel window. Special 0-xxx two-part channel commands are supported for display input selection, captions, and
other functions.
Channel Type Major # Minor #
Two-part Digital <0-999> <0-999>
One-part Digital <1-9999> Leave Blank
Analog <2-135> <0>
