Yamaha A-S801 Integrated Amplifier (Silver) - Manual (Page 18)

14
En
PLAYBACK OF MUSIC FILES STORED ON A PC (USB DAC)
■
Playing back music files stored on the
PC
1
Connect the PC to this unit, using a USB
cable.
2
Turn on the PC.
3
Press A (power) switch on the front panel
inward to turn on this unit.
4
Rotate the INPUT selector on the front panel
(or press one of the Input selector buttons on
the remote control) to select the USB.
5
Set the audio output destination of the PC to
“Yamaha USB DAC”
With Windows OS:
Control Panel ➝ Hardware and Sound ➝ Sound ➝
[Playback] tab
With Mac OS:
System Preferences ➝ Sound ➝ [Output] tab
The setting may vary, depending on the operating
system. For details, consult the manufacturer of your
PC.
6
Operate the PC to start playback of music
files.
When the music signal input from the PC to the unit,
the USB DAC indicator on the front panel lights up in
accordance with the sampling frequency of the song
being played.
■
Adjusting the sound volume
To obtain higher sound quality, set the sound volume at
the PC to the maximum, and gradually increase the
volume at this unit from the minimum to your desired
level.
• Do not disconnect the USB cable, turn off the unit, or change
the input while playback on a PC connected via the USB cable
is in progress. Doing so may cause a malfunction.
• To mute operation sounds of the PC during music playback,
change the setting on the PC.
• If music files cannot be played correctly, restart the computer
and perform the mentioned procedure again.
• The music files stored on a PC cannot be controlled from this
unit or the remote control of this unit. Operate them on the PC.
USB DAC
indicators A INPUT
A AMP
USB
Indicator Frequency
PCM
× 1 44.1/48 kHz
× 2 88.2/96 kHz
× 4 176.4/192 kHz
× 8 352.8/384 kHz
DSD
× 1 2.8224 MHz
× 2 5.6448 MHz
Notes
