10
ADC card DB25 pin out configurations
Pin No. Jumpers
disabled
(default)
ProTools™
Compatible 44.1
- 96kHz
Jumpers
disabled
ProTools™
Compatible
Dual Wire Mode
88.2 - 192kHz Jumpers
enabled Single
Wire Mode 44.1 -
192kHz Jumpers
enabled + S/
PDIF
Switch In -
Single Wire
Mode 44.1 -
192kHz Jumpers
enabled +
Dual Wire Mode
88.2 - 192kHz Jumpers
enabled + S/
PDIF
Switch In + Dual
Wire
Mode 88.2 -
192kHz
1 NC NC AES 7/8+ AES 7/8+ AES 8+ AES 4+
2 GND GND GND GND GND GND
3 NC NC AES 5/6- AES 5/6- AES 7- AES 3-
4 NC NC AES 3/4+ AES 3/4+ AES 6+ AES 2+
5 GND GND GND GND GND GND
6 NC NC AES 1/2- AES 1/2- AES 5- AES 1-
7 AES 7/8+ AES 4+ AES 7/8+ SPDIF 7/8+ AES 4+ SPDIF 7/8+
8 GND GND GND GND GND GND
9 AES 5/6- AES 3- AES 5/6- SPDIF 5/6+ AES 3- SPDIF 5/6-
10 AES 3/4+ AES 2+ AES 3/4+ SPDIF 3/4+ AES 2+ SPDIF 3/4+
11 GND GND GND GND GND GND
12 AES 1/2- AES 1- AES 1/2- SPDIF 1/2- AES 1- SPDIF 1/2-
13 NC NC NC NC NC NC
14 NC NC AES 7/8- AES 7/8- AES 8- AES 4-
15 NC NC AES 5/6+ AES 5/6+ AES 7+ AES 3+
16 GND GND GND GND GND GND
17 NC NC AES 3/4- AES 3/4- AES 6- AES 2-
18 NC NC AES 1/2+ AES 1/2+ AES 5+ AES 1+
19 GND GND GND GND GND GND
20 AES 7/8- AES 4- AES 7/8- SPDIF 7/8- AES 4- SPDIF 7/8-
21 AES 5/6+ AES 3+ AES 5/6+ SPDIF 5/6+ AES 3+ SPDIF 5/6+
22 GND GND GND GND GND GND
23 AES 3/4- AES 2- AES 3/4- SPDIF 3/4- AES 2- SPDIF 3/4-
24 AES 1/2+ AES 1+ AES 1/2+ SPDIF 1/2+ AES 1+ SPDIF 1/2+
25 GND GND GND GND GND GND
24-bit/192kHz ADAT™ interface operation
The card provides digital outputs for all eight ISA428 MkII channels, which operate over the sample frequency ranges 44.1-192kHz.
The card features two ADAT™-type ‘lightpipe’ output connectors. For speeds up to 48kHz, both connectors transmit all 8 channels
simultaneously. However, ADAT™-type connectors are bandwidth-limited at sample rates 88.2kHz and 96kHz - each audio channel
uses two ADAT™ digital channels to accommodate the increased quantity of data (SMUXII). At sample rates 176.4kHz and 192kHz,
each audio channel uses four ADAT™ digital channels to accommodate the increased quantity of data (SMUXIV).
The ADAT™ output connectors operate as follows:
44.1/48kHz sample rates:
Connector 1 = channels 1 to 8
Connector 2 = channels 1 to 8 (identical to connector 1)
88.2/96kHz sample rates:
Connector 1 = channels 1 to 4
Connector 2 = channels 5 to 8
176.4/192kHz sample rates:
Connector 1 = channels 1 and 2
Connector 2 = channels 3 and 4
