10. Factory Reset
Long press ≥ 3 seconds, wait 3 minutes and the screen will appear with the ifi logo.
DO NOT POWER OFF!
Warning: Loss of power during this period may damage your device and leave it unusable.
11. Optical Ethernet Input
Connect with an SC single mode optical network cable.
Alternatively connect the included OptiBox RJ45 to optical transceiver with the SC-SC cable.
12. USB-C System Update Port
Used for system firmware update (by factory).
13. USB Type A x 2 Ports
Compatible with USB 2.0 and USB 3.0.
a) Output - Connect to USB DAC
b) Input - Connect to HDD, USB DISK etc.
Both USB ports have Active Noise Cancellation (ANC) technology built-in.
14. I2S Output
I2S digital output via HDMI connector. Connects to a compatible DAC. The level complies with
the low voltage differential signal (LVDS) standard. For the pinout, please see Specifications.
