10
Power Switch
I2S Output
RJ45 Ethernet
M12 Ethernet System Update RCA Analogue Line Output AES/EBU Outputs
S/PDIF Coaxial Output USB Type-A IN/OUT
Wi-Fi Antenna
Short press: Menu
USB-C Input/Output Optical Input
4.4 BAL Analogue Line Output S/PDIF Optical Output
Long press: Output Selector
*A power supply unit must be able to deliver minimum rated repetitive current.
*Only one ethernet connection shall be used at any given time.
DC 9V/2.0A, 12V/1.8A, 15V/1.2A*
DC 9V/12V/15V*
Quick Start Guide
Selector Knob
1 Power
2 Input
RJ45* USB*
M12* Optical SC*
USB-C
Wi-Fi
Network Status
