Specifica
tions
Inpu
ts:
Wi-Fi
Ethernet
(M12
X-code
8-pin/RJ45/Optical)
USB-A and USB-C (front panel) (USB DISK, HDD etc.)
Formats:
DSD: up to 512 / 22.6MHz
PCM:
up
to
768kHz
MQA
Full
Decoder
Analogue output:
Balanced 4.4mm 4V RMS / UnBAL RCA 2V RMS
Digital output:
USB-C (front panel)
USB3.0 Type-A Socket x2 (USB2.0 compatible)
S/PDIF Optical (PCM up to 192kHz, 24-bit)
S/PDIF Coaxial (PCM up to 192kHz, 24-bit)
AES/EBU (XLR - single link, PCM up to 192kHz)
I2S via HDMI connector
Pinout: 1) Data -
2) Gnd
3) Data +
4)
Bck
+
5)
Gnd
6)
Bck
-
7)
Wck
-
8)
Gnd
9)
Wck
+
10)
Mck
+
11)
Gnd
12)
Mck
-
13,14,15,16)
DSD
Enable;
L=PCM,
H=DSD
17) Gnd
18) 5V Power Enable Output; L=Off, H=On
19)
N/C
20,21,22,23)
Gnd
15
