7
4. Menu/Output Selector
Short press: Displays the current digital filter set. To change the digital filter, press the knob to enable
selection, turn to change the filter, and press the knob again to confirm. Please see item 2, VIII.
Long press: Displays the output setting. Choose between Analogue, Digital, or USB DAC audio
(if connected) by turning the knob, and press the knob again to confirm.
5. Power Switch And Indicator
Short press to switch on, long press ≥ 2s to switch off.
6. USB-C Input/Output
a) Output - Connect to USB DAC
b) Input - Connect to HDD, USB DISK etc.
Tip: The USB-C connector has Active Noise Cancellation (ANC) technology built-in.
7. DC Power Supply Connection
DC 9V/2.0A, 12V/1.8A, 15V/1.2A* power input. Please connect NEO Stream to the enclosed power supply.
8. M12 Ethernet Input
Connect a network cable with an M12 X-code 8-pin connector.
9. RJ45 Ethernet Input
Connect a wired network cable with a RJ45 connector.
*A power supply unit must be able to deliver minimum rated repetitive current.
