Table 3. WD22TB4 for Thunderbolt systems (continued)
Display Port
Available
Bandwidth
Single Display
(maximum
resolution)
Dual Display
(maximum
resolution)
Triple Display (maximum
resolution)
Quad Display (maximum
resolution)
Type-C TB: 4K (3840
x 2160) @60 Hz
● DP 1.4 + HDMI
2.0: QHD (2560 x
1440) @60 Hz
● DP 1.4 + MFDP
Type-C: QHD
(2560 x 1440)
@60 Hz
● DP 1.4 + TBT
Type-C: 4K (3840
x 2160) @60 Hz
● HDMI 2.0 + TBT
Type-C: 4K (3840
x 2160) @60 Hz
● MFDP Type-C +
TBT Type-C: 4K
(3840 x 2160)
@60 Hz
1440) @60 Hz + 1 x
FHD (1920 x 1080)
● DP 1.4 + DP 1.4 +
MFDP Type-C: 2 x QHD
(2560 x 1440) @60 Hz
1 x FHD (1920 x 1080
● DP 1.4 + DP 1.4 +
TBT Type-C : 3 x QHD
(2560 x 1440) @60 Hz
● DP 1.4 + MFDP Type-C
+ TBT Type-C: 3 x QHD
(2560 x 1440) @60 Hz
● DP 1.4 + HDMI 2.0 +
TBT Type-C: 3 x QHD
(2560 x 1440) @60 Hz
HBR3 (HBR3 x4
lanes + HBR3 x1 -
32.4 Gbps) DP 1.4/HDMI
2.0/MFDP Type-
C/TBT Type-C: 4K
(3840x4320) @60Hz ● DP 1.4 + DP 1.4:
4K (3840 x 2160)
@60 Hz
● DP 1.4 + HDMI
2.0: 4K (3840 x
2160) @60 Hz
● DP 1.4 + MFDP
Type-C: 4K (3840
x 2160) @60 Hz
● DP 1.4 + TBT
Type-C:
○ 1 x 4K (3840 x
2160) @60 Hz
○ 1 x QHD
(2560 x 1440)
@60 Hz
● HDMI 2.0 + TBT
Type-C:
○ 1 x 4K (3840 x
2160) @60 Hz
○ 1 x QHD
(2560 x 1440)
@60 Hz
● MFDP Type-C +
TBT Type-C:
○ 1 x 4K (3840 x
2160) @60 Hz
○ 1 x QHD
(2560 x 1440)
@60 Hz
● DP 1.4 + DP 1.4 + HDMI
2.0:
○ 1 x 4K (3840 x
2160) @60 Hz
○ 2 x QHD (2560 x
1440) @60 Hz
● DP 1.4 + DP 1.4 +
MFDP Type-C:
○ 1 x 4K (3840 x
2160) @60 Hz
○ 2 x QHD (2560 x
1440) @60 Hz
● DP 1.4 + DP 1.4 + TBT
Type-C:
○ 2 x 4K (3840 x
2160) @60 Hz
○ 1 x QHD (2560 x
1440) @60 Hz
● DP 1.4 + MFDP Type-C
+ TBT Type-C:
○ 2 x 4K (3840 x
2160) @60 Hz
○ 1 x QHD (2560 x
1440) @60 Hz
● DP 1.4 + HDMI 2.0 +
TBT Type-C:
○ 2 x 4K (3840 x
2160) @60 Hz
○ 1 x QHD (2560 x
1440) @60 Hz
● DP 1.4 + DP 1.4 +
HDMI 2.0 + TBT Type-
C: QHD (2560 x 1440)
@60 Hz
● DP 1.4 + DP 1.4 +
MFDP Type-C + TBT
Type-C: QHD (2560 x
1440) @60 Hz
HBR3 with DSC
(Display Stream
Compression)
DP 1.4/HDMI
2.0/MFDP Type-
C/TBT Type-C: 4K
(3840x4320) @60Hz
● DP 1.4 + DP 1.4:
4K (3840 x 2160)
@60 Hz
● DP 1.4 + HDMI
2.0: 4K (3840 x
2160) @60 Hz
● DP 1.4 + DP 1.4 + HDMI
2.0:
○ 3 x 4K (3840 x
2160) @60 Hz
● DP 1.4 + DP 1.4 +
MFDP Type-C:
● DP 1.4 + DP 1.4 + HDMI
2.0 + TBT Type-C:
3 x 4K (3840 x 2160)
@60 Hz + 1 x QHD
(2560 x 1440) @60 Hz
OR
