Preparation/Basics
68
Charging the battery
• The battery that can be used with this unit is BP-DC12.
• We recommend charging the battery in ambient temperatures between +10 °C
and +30 °C (+50 °F to +86 °F) and with the battery at the same temperature.
Insert the battery into the camera.
Make sure that the camera is turned off when inserting the battery.
[USB/CHARGE] jack
•This terminal is located at the bottom when the camera is in
an upright position.
•Always check the direction of the jack, and hold the plug straight to insert or remove it. (If the
cable is inserted in the wrong direction, the jack could become deformed and cause faulty
operation.) Also, do not insert into the wrong jack. Doing so may cause damage to this unit.
Battery charge indicator (Red)
AC adaptor (supplied)
To the mains power socket
USB cable (supplied)
Computer
•Turn on the computer.
■
Charging time
When using the AC adaptor (supplied) Approx. 180 min.
•The time required for charging through the computer varies depending on the power
supply capacity of the computer.
●
Do not use any other USB cables except the supplied one.
●
Do not use any other AC adaptors except the supplied one.
