LEICA V-Lux 5 Digital Camera - Manual (Page 70)

Preparation/Basics
70
[EVF] button (Taking pictures via the viewfinder)
1 Press the [EVF] ( ) button
Automatic switchover from
viewfinder to monitor display
Viewfinder display Monitor display
■
Automatic switchover between viewfinder and monitor
The eye sensor ( ) automatically switches the display
to viewfinder when your eye or an object approaches the
viewfinder. When the eye or object moves away from the
viewfinder, the camera returns to monitor display.
■
Diopter adjustment
Turn the diopter adjustment dial until you see clearly through
the viewfinder.
●
If [EVF Display Speed] is set to [ECO 30fps] when the
viewfinder is used, the camera can be operated for a longer
period since battery drainage is reduced.
Handling the camera correctly
•Do not block the flash, AF Assist
Lamp, microphone, or speaker with
your fingers or other objects.
Speaker
AF Assist Lamp
Microphone
•Keep your fingers away from the lens barrel while
focusing as the retracting lens could trap your
fingers.
