PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
name string[40] 6/6 Identification of this entry.
enable 0, 1 6/6 Enable or disable this event.
priority 0, 1, 2 6/6 Indicate the priority of this event:
"0"= low priority
"1"= normal priority
"2"= high priority
delay 1~999 6/6 Delay in seconds before detecting the
next event.
trigger boot,
di,
pir,
motion,
seq,
recnotify,
tampering,
vi,
volalarm,
visignal,
vadp,
smartsd,
presetreached,
casingopen
<product
dependent>
6/6 Indicate the trigger condition:
"boot" = System boot.
"di"= Digital input.
"pir"= PIR detection.
"motion" = Video motion detection.
"seq" = Periodic condition.
"visignal" = Video input signal loss.
"recnotify" = Recording notification.
"tampering" = Tamper detection.
"vi"= Virtual input (Manual trigger).
"volalarm"= Audio detection.
"smartsd"= Lifetime detection of SD card.
"shockalarm" = Shock detection.
"virestore" = Video input signal restore.
"vadp" = VADP trigger.
"presetreached" = When any preset is
reached
"casingopen" = Casing open detection
* "smartsd" is only valid when smart SD
card is inserted
triggerstatus string[40] 6/6 The status for event trigger
© 2022 VIVOTEK INC. All Right Reserved
215
PARAMETER VALUE SECURITY
(get/set) DESCRIPTION
di 0,<positive
integer> 6/6 Indicate the source id of di trigger.
This field is required when trigger
condition is “di”.
One bit represents one digital input. The
LSB indicates DI 0.
* Only available when "capability_ndi" >
0
mdwin 0,<positive
integer> 6/6 Indicate the source window id of motion
detection.
This field is required when trigger
condition is “md”.
One bit represents one window.
The LSB indicates the 1
st window.
For example, to detect the 1 st and 3 rd
windows, set mdwin as 5.
mdwin0 0,<positive
integer> 6/6 Similar to mdwin. The parameter takes
effect when profile 1 of motion detection
is enabled.
vi 0,<positive
integer> 6/6 Indicate the source id of vi trigger.
This field is required when trigger
condition is “vi”.
One bit represents one digital input. The
LSB indicates VI 0.
vadp
<product dependent>
0,<positive
integer> 6/6 Indicate the source id of vadp event
notification.
Each bit corresponds to one vadp source,
and the LSB indicates source id 0.
For example, to detect event from any
one of source id 0, 1 and 3, set vadp to
11.
* Only available when vadp is listed in
"capability_supporttriggertypes"
valevel 0,1 6/6 Select audio detection event.
0: not select
1: select
