Senal AWS-24G 2-Person Wireless Microphone System for Cameras and Smartphones (2.4 GHz) - Manual (Page 20)

Receiver Type
Receiver
Beltpack
Wireless Frequency 2400 to 2483 MHz
Transmitting Power +10 dBm
Sensitivity -86 dBm
S/N >70 dB
Latency <20 ms
Mounting Options Belt clip
Antenna PCB internal
Number of Audio Channels 2
Audio I/O 1/8 in. (3.5 mm) TRS female unbalanced mic output
Gain Range -12 to +12 dB (2 dB increments)
USB/Lightning Connectivity USB Type-C (charging, audio)
Power Requirements Battery or bus power (USB-C)
Battery Type Built-in Li-ion 330 mAh / 3.7 V
Approx Battery Life 6 hr.
Display and Indicators LCD (Operating mode, battery level, audio level metering,
output gain, transmitters battery level, active channel)
Dimensions 1.8 Ч 1.8 Ч 0.9 in. (4.5 Ч 4.5 Ч 2.2 mm)
Weight 1 oz. (28 g)
18
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
