Transmitter Type
Transmitter Transmitter
Bodypack with microphone
Wireless Frequency 2400 to 2483 MHz
Sensitivity -86 dBm
S/N >70 dB
Frequency Response 80 Hz to 20 kHz
RF Output Power 10 mW
Audio I/O USB Type-C
Muting On/off switch
Recorder Sample Rate 48 kHz
Recorder Bit Depth 16 bit
Audio File Formats WAV
Gain Range -12 to +12 dB
Signal Processing None
Sync Method Proprietary
Antenna PCB internal
Power Requirements Battery or bus power
Battery Type Built-in rechargeable
Approx Battery Life 5 HoursNormal Recording Mode)
3.5 HoursOn-board Recording Mode)
Recording Time 24 hr.
USB/Lightning I/O USB Type-C (data, charging)
Analog I/O 1/8 in. (3.5 mm) unbalanced mic input
Display and Indicators LCD (RF signal strength, pairing, mute,
battery level, recording status, recorded
time, channel indicator, audio meter)
Dimensions 1.8 Ч 1.8 Ч 0.9 in. (4.5 Ч 4.5 Ч 2.2 mm)
Weight 1 oz. (28 g)
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
19
