6-1
6.1
General wiring guidelines
6
Wiring
66000
Wiring
Wiring
6-
6.1
General wiring guidelines
6100
General wiring guidelines
6-
Verdrahtung_PDP_PSEN
Please note:
Information given in the “Technical details” must be followed.
Where safety-related applications are concerned, it is essential that
short circuits and open circuits are unable to cause a hazardous con-
dition within a plant. The way in which this is done will depend on the
degree of hazard from the plant, the switching frequency of the sen-
sors and the level of safety of the sensors and actuators.
You can use prefabricated sensor cables from Pilz for connecting the
sensors.
CAUTION!
In order to guarantee protection type IP67, unused plug-in con-
nectors should be sealed using the blind plugs supplied.
