7-1
7.1 Messages
7 Operation
77000 Operation Operation 7- 7.1 Messages 7100 Messages 7- Betrieb_Meldungen_PDP_PSEN
The module is ready for operation when the "Power" LED is lit continu-
ously.
7.1.1 Display elements for device diagnostics
Display elements for device diagnostics 7- Anzeige Legende 3x
Legend:
Betrieb_Anzeige_PDP_PSEN
LED on
LED flashes
LED off
LED LED status Meaning
Power green The unit is ready for operation
The unit is not ready for operation
Diag green The actuator is within the response range
The actuator is not within the response range
Lock green Control command for magnetic guard locking available
Control command for magnetic guard locking not available
