6.3 Preparing for operation 6300 Preparing for operation 6-
6.3.1 Connection
Connection 6- Anschluss_PDP_PSEN_Allgemein
Please note:
 A maximum of 4 sensors per module can be connected to female
connectors X1 ... X4. Note the current load capacity of the modules
(see current load capacity for UB)
 The evaluation device is always connected to the last non-assigned
female connector X2 ... X5.
 The adapter PDP67 Connector cs/PDP67 Connector cs VA must
be used for connecting the evaluation device and for connecting the
modules in series. The adapter requires the use of a female connector
for connecting the supply voltage. This prevents the risk of a short cir-
cuit from contact with the contacts of a male connector.
 The signal outputs (Diag) of the connected sensors are connected to
pins 1 to 4 of the X6 female connector.
 The control commands for magnetic guard locking ("Lock_Unlock")
for PSENslock are connected to pins 5 to 8 of the X6 female connec-
tor.
 The sensors must always be connected to the module in consecutive
order.
Example:
– Correct: Sensor to female connector X1, X2, X3
– Wrong: Sensor to female connector X1, X2, X4
Anschlussbeispiele_Achtung
Verdrahtung_PDP_SEN_Rückfallverzögerung_Hinweis
Please refer to the chapter entitled “Technical details” in the operating
manual for the sensors used for the delay-on de-energisation times.
CAUTION!
When several units are connected in series, the delay-on de-
energisation time increases in direct proportion to the number of
interconnected safety switches.
