4. USER INTERFACE (continued...) --
4.5 MEMORY SWITCH SETTINGS
MSW1–0
Enables control of manual output through an external analog input.
See Section 3.6 for details.
MSW1–1
Enables control of tension setpoint with an external analog input
See Section 3.6 for details.
MSW1–2
Enables diameter measurement with an external analog input
See Section 6.3 and 6.4 for details
MSW1–3
Enables setting the diameter of a new roll with an external analog input for use with the splicing
operation. See Section 3.6 and 7.3 for details.
MSW1–4
Enables setting the start level with an external analog input.
See Section 3.6 for details.
MSW1–5
Enables setting the taper ratio with an external analog input. Overrides Parameter No. 14 (Taper Ratio).
See Section 3.6 for details.
MSW1–6, 7
Sets the function of the analog monitoring outputs on terminal pairs 27-28 & 29-30.
TEN:
Actual Tension Measurement
DIA:
Diameter Measurement
MEMORY DIP SWITCH 1 (MSW1)
7
6
5
4
3
2
1
0
0: External Manual Output
1: External Tension Setpoint
2: Analog Diameter Input
3: New Shaft Diameter Setting
4: External Start Level
5: External Taper Ratio
6-7: Logging Output
: Enabled
: Enabled
: Enabled
: Enabled
: Enabled
: Enabled
: – –
:
*
–
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
TEN
DIA
7 6 5 4 3 2 1 0
– – – – – – – –
MSW1
ON (*) OFF (–)
NOTE
The underline indicates a position set at the factory.
