Altera Cyclone III FPGA Starter Board User Manual
Page 26
2–18
Altera Corporation
Cyclone III FPGA Starter Board Reference Manual
April 2012
Memory
flash_sram_a14
C10 Output
2.5 V
50
flash_sram_a15
D10 Output
2.5 V
81
flash_sram_a16
E10 Output
2.5 V
82
flash_sram_a17
C9 Output
2.5 V
99
flash_sram_a18
D9 Output
2.5 V
100
flash_sram_a19
A7 Output
2.5 V
43
flash_sram_a20
A6 Output
2.5 V
42
flash_sram_a21
B18
Output
2.5 V
39
flash_sram_a22
C17 Output
2.5 V
38
flash_sram_dq0
H3 Bidirectional
2.5
V
52
flash_sram_dq1
D1 Bidirectional
2.5
V
53
flash_sram_dq2
A8 Bidirectional
2.5
V
56
flash_sram_dq3
B8 Bidirectional
2.5
V
57
flash_sram_dq4
B7 Bidirectional
2.5
V
58
flash_sram_dq5
C5 Bidirectional
2.5
V
59
flash_sram_dq6
E8 Bidirectional
2.5
V
62
flash_sram_dq7
A4 Bidirectional
2.5
V
63
flash_sram_dq8
B4 Bidirectional
2.5
V
68
flash_sram_dq9
E7 Bidirectional
2.5
V
69
flash_sram_dq10
A3 Bidirectional
2.5
V
72
flash_sram_dq11
B3 Bidirectional
2.5
V
73
flash_sram_dq12
D5 Bidirectional
2.5
V
74
flash_sram_dq13
B5 Bidirectional
2.5
V
75
flash_sram_dq14
A5 Bidirectional
2.5
V
78
flash_sram_dq15
B6 Bidirectional
2.5
V
79
flash_sram_dq16
C16 Bidirectional
2.5
V
2
flash_sram_dq17
D12 Bidirectional
2.5
V
3
flash_sram_dq18
E11 Bidirectional
2.5
V
6
flash_sram_dq19
D2 Bidirectional
2.5
V
7
flash_sram_dq20
E13 Bidirectional
2.5
V
8
flash_sram_dq21
E14 Bidirectional
2.5
V
9
flash_sram_dq22
A17 Bidirectional
2.5
V
12
flash_sram_dq23
D16 Bidirectional
2.5
V
13
flash_sram_dq24
C12 Bidirectional
2.5
V
18
Table 2–16. SSRAM Pinout (Part 2 of 3)
Signal Name
FPGA Pin
Direction
Type
U5 (SSRAM) Pin
