68
2D Barcodes
OS-2140 & OS-2140D:
PPLA/PPLB/PPLZ: MaxiCode, PDF417, Data Matrix (ECC 200
only), QR code, Composite codes
OS-214plus:
PPLA: PDF-417, MaxiCode, Data Matrix (ECC200 only) ,QR
Code, Composite codes
PPLB: MaxiCode, PDF-417, QR Code, Composite codes
Graphic
OS-2140 & OS-2140D:
PPLA/PPLB: PCX, BMP, IMG, HEX,GDI, Binary raster(PPLB
Only)
PPLZ: GRF, Hex and GDI
OS-214plus:
PPLA: PCX, BMP, IMG, HEX ,GDI
PPLB: PCX, Binary raster , GDI
Emulation PPLA/PPLB/PPLZ (OS-2140Z,OS-2140DZ only)
Software-Label
editing
Windows Driver (Win 2003/XP/Vista/Windows 7) BarTender ,
Software-Utility Printer Utility, Font Utility
Media Type
Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal
paper or plain paper and fabric label
Media
Max Width:4.33”(110mm) Min Width:1”(25.4mm)
Thickness:0.0025”~0.01”(0.0635~0.254mm)
Max roll capacity(OD):4.3”(109mm)
Core size:0.5”(12.7mm) (1”(25.4mm) optional)
Ribbon N/A
Ribbon Width: 1”~4”
Ribbon roll – max OD: 1.45”(37mm)
Ribbon Length: max 92m
Core size – ID: 0.5”(13mm) with notch
Wax, Wax/Resin, Resin (Outside Ribbon)
Dimensions W 186mm x H 153mm x L 278mm
Weight 2.0kgs
Power Source
Universal Switching Power Supply Input: 100V~240V,
1.5A, 50~60Hz, Output: 24VDC, 2.4A
Operation
Environment
Operation Temperature: 40F~100F (4C~38C), 10% ~ 90%
non-condensing,
Storage Temperature: -4F~122F (-20C~50C)
69
Optional Items
Cutter, Stacker, RTC Card, ArgoKee, 2MB Asian Font Card
(Traditional Chinese, Simplified Chinese, Korean and
Japanese)
Agency Listing
CE, FCC, cTUVus, CCC,
