BE1-79M Installation
9170100990 Rev N
Figure 4-3. S1 Case Dimensions, Side View, Double Ended, Semi-Flush Mount
.75
(19.1)
(157.2)
6.19
(49.53)
1.95
10-32 SCREWS
(7.9)
.31
10-32 SCREWS
(102.4)
4.03
4.03
(102.4)
(7.9)
.31
MOUNTING PANEL
(55.75)
2.195
P0066-64
