Hardware Installation
Cooling Option
Heat Sink with Cooling Fan
• “1” to “10” denote the locations of the
thermal pads designed to contact the
corresponding components that are on
CA900-B.
• Remove the plastic covering from the
thermal pads prior to mounting the
heat sink onto CA900-B.
Top View of the Heat Sink
Bottom View of the Heat Sink
1
2
3
4
5
6
7
8
9
10
