COM Express Board
29
Cooling Options
Heatspreader
Heatspreader on G5C900-B
(top view)
Bottom View of the Heatspreader
• "1" to "5" denote the locations of the thermal pads
designed to contact the corresponding components
that are on G5C900-B.
• Remove the plastic covering from the thermal pads
prior to mounting the heatspreader onto G5C900-B.
1
2
3
4
5
